The control cabinet has two modes, automatic and manual modes.
The unit length of the targeted sheet and quantity can be set in the touchscreen.
The system is simple and easy to operate.
Electrical Component Brand:
1. VFD: Delta
2. Circuit breaker: Delixi
3. Contactor: Delixi
4. Relay: Xinling
5. PLC: Delta
6. Transformer: Delixi
Feeding Table & Pre-Cutter
Guide the coil come into the correct position and going to the roll forming part.
Also including a Hand Pull Cutting Device, it is convenient to pre-cut the coil when want to changing color or thickness.
Shaft & Roller
Material is 45# Steel Quenching and Plating.
The processed rollers are smooth, hard and will not rust.
Will not leave any scratches on the sheet when working.
Pressing Section & Cutter
The material of blade is CR12.
After shaping, the metal is cut into individual slats of the required length. Precision cutting ensures uniformity in the final product.
After the plate is led out from the unloading rack, it passes through the feed guide roller and enters the main body of the tile press. The function of the feed guide roller is to guide the plate accurately into the forming mechanism, and at the same time to perform preliminary leveling of the plate, reduce the wave and distortion of the plate surface, and provide a good foundation for the subsequent forming process. Some advanced double-layer trapezoidal tile presses are also equipped with a centering device at the feed end, which can automatically detect the position of the plate and adjust it to ensure that the plate remains in the center position during the entire pressing process.
